SCM Tech 99 - masina gaurit lemn 4 axe

SCM Tech 99 - masina gaurit 4 axe

  Oferi: C.N.C. WORKING CENTER (POINT TO POINT) SCM Tech 99 H
   Producator: SCM
   Tip: Tech 99 H
   Anul fabricatiei: 2002
   Starea masinii: Ready for operation
   Tipul ofertei: Masina folosita
   Locatia masinii: Brasov - Romania

   Date tehnice: C.N.C. WORKING CENTER (POINT TO POINT) with 4 axis (X-Y-Z-C)
  - CE mark
  - Complete safety enclosure on the working head (Soft Impact Bumpers)
  - Goose-neck type machine
  - Numerical Control ESA Tria and software XILOG
  - Automatic Tool Changing System on the working head (No. 4 storage places for tools)
  - Max X axe stroke for vertical electro-spindle (router) mm 3300
  - Max Y axe stroke for vertical electro-spindle (router) mm 1340
  - Max Y axe stroke for vertical drilling bits mm 1120
  - Max Z axe stroke mm 200 (max workpieces/panel passage mm 180)
  - Lenght of the working supports/rails mm 1200
  - No. 1 Vacuum Pump (100 m3/h capacity)
  - No. 14 independent vertical boring spindles (for X and Y axes)
  - No. 6 independent horizontal boring spindles (for X and Y axes)
  - No. 1 Vertical electro-spindle (router) power HP 9, with access to the Tool change System
  - No. 1 Circular saw Unit, rotating 0°-90° by C.N., max diam. mm 200
  - Total installed power KW
